ER20/EH96/Clear, Semi – Flexible Potting & Laminating System/1,2 kg

Resin ER20 – Hardener EH96



ER20 Resin:             1 x 1 kg       Bottle

EH96 Hardener:    1 x  200 g   Bottle



Low viscosity, clear, semi-flexible, tough epoxy laminating resin system for room temperature foundry patterns and master moulds.

Also used as a potting resin for electronic components. Minimum Irritation Potential Hardener.

ER20 – EH96 is used with fiberglass tooling fabrics for laminated moulds, with cotton flocks as a coupling coat behind gelcoats, and mixed with sand or other fillers as a casting or ramming concrete to reinforce patterns and negatives.

EH96 gives a higher HDT after post-curing at 100 C.



Description

Colour:

Resin ER20 : Clear

Hardener EH96: Clear

Mixing Ratio:

ER20              100             parts by weight

EH96               20

Viscosity:

ER20        1200 to 1400 mPa.s at 25 Deg. C

EH96       300 to 500 mPa.s at 25 Deg. C

Density:               1,1

Pot Life:               30 to 40 minutes at 25 Deg. C

Gelation Time:     2  to 3 Hours at 25 Deg. C

(Gelnorm DIN 16945, test tube, 16 mm dia.)

Curing Time:  24 hours at 25 Deg. C        or

                              7 hours at 40 Deg. C

CHARACTERISTICS after CURE

(Approximate)

Tensile strength:                 40 – 60 MPa

Elongation at break:           2,5 – 3,5%

Hardness:           65 Shore D after 7 days at 25 Deg. C

Flexural Strength:         80 – 100 MPa

Impact Strength:            40 KJ/m2

Heat Distortion Temperature:        50 Deg. C

 (after post-curing @ 70 C)                70 Deg. C

(after post-curing @ 100 C)               100 Deg. C

Dielectric Strength:                        18 KV / mm

Dielectric constant: at 23               4,1 – 4,3



The above data are offered for customer’s guidance only. It implies no guarantee. Customers must conduct their own tests to determine the suitability of the material for their specific applications.
