ER20/EH96/Clear, Semi – Flexible Potting & Laminating System/1,2 kg

SKU: ER20/1,2Kg(1x1,2kg) Categories: , , ,

Resin ER20 – Hardener EH96



ER20 Resin:             1 x 1 kg       Bottle
EH96 Hardener:    1 x  200 g   Bottle



Low viscosity, clear, semi-flexible, tough epoxy laminating resin system for room temperature foundry patterns and master moulds.

Also used as a potting resin for electronic components. Minimum Irritation Potential Hardener.

ER20 – EH96 is used with fiberglass tooling fabrics for laminated moulds, with cotton flocks as a coupling coat behind gelcoats, and mixed with sand or other fillers as a casting or ramming concrete to reinforce patterns and negatives.

EH96 gives a higher HDT after post-curing at 100 C.



Description

Colour:

Resin ER20 : Clear

Hardener EH96: Clear

Mixing Ratio:

ER20              100             parts by weight

EH96               20

Viscosity:

ER20        1200 to 1400 mPa.s at 25 Deg. C

EH96       300 to 500 mPa.s at 25 Deg. C

Density:               1,1

Pot Life:               30 to 40 minutes at 25 Deg. C

Gelation Time:     2  to 3 Hours at 25 Deg. C

(Gelnorm DIN 16945, test tube, 16 mm dia.)

Curing Time:  24 hours at 25 Deg. C        or

                              7 hours at 40 Deg. C

CHARACTERISTICS after CURE

(Approximate)

Tensile strength:                 40 – 60 MPa

Elongation at break:           2,5 – 3,5%

Hardness:           65 Shore D after 7 days at 25 Deg. C

Flexural Strength:         80 – 100 MPa

Impact Strength:            40 KJ/m2

Heat Distortion Temperature:        50 Deg. C

 (after post-curing @ 70 C)                70 Deg. C

(after post-curing @ 100 C)               100 Deg. C

Dielectric Strength:                        18 KV / mm

Dielectric constant: at 23               4,1 – 4,3



The above data are offered for customer’s guidance only. It implies no guarantee. Customers must conduct their own tests to determine the suitability of the material for their specific applications.

Weight 1.2 kg
Dimensions 24.5 × 15.5 × 25 cm
